* Cast aluminum frame
* Dual 4 Ohm voice coils
* Aluminum wire voice coil
* 400 watts power handling
* 1,000 peak power handling
* Lead wires woven into spider

* 2 inch peak-to-peak excursion

* Gold-plated 5-way binding posts
* Extra-thick multi-layer foam surround
* Copper shorting ring to reduce distortion
* Large motor system with (2) 73 oz magnets

Fs 35 Hz
Sensitivity 91.5 dB
Impedance 4 Ohms, each coil
Re 3.2 Ohms, each coil
Qms 4.81
Qes 0.43
Qts 0.40
VAS 50.4 litres
Mms 141.0 grams
Cms 137 IM / Newton
BL 19.6 Tesla-M
The Prestige Series Cannon Subwoofer is best way for adding extraordinary bass extension to your system.  The Cannon was designed to play deep and hard without sounding muddy or out of control.  The large vented magnet system, copper shorting ring, special multilayer surround all contribute to making this subwoofer attack the lowest notes with speed and accuracy. It can easily be integrated into your system with a 1.5 cubic foot sealed cabinet.  It can even play in a smaller vented box from 0.75-1.0 cubic feet.
